H5Col: Column-Oriented Tabular Data in HDF5

1Introduction¶

HDF5 has stored tabular data from its earliest days, and several distinct idioms have grown up around that use case. HEP001 proposes a column-oriented storage layout, in the spirit of Apache Parquet, Apache Arrow, and Feather, that lives natively as an HDF5 group and combines cleanly with the multidimensional array datasets that are HDF5’s traditional strength.

1.1A short overview of tabular data in HDF5¶

The first adopted idiom is the HDF5 Table specification, part of the HDF5 High-Level Library and implemented through its H5TB API. A table is a single one-dimensional dataset whose datatype is an HDF5 compound (record) type, decorated with attributes such as CLASS="TABLE", VERSION, TITLE, FIELD_0_NAME … FIELD_N_NAME, FIELD_0_FILL … FIELD_N_FILL, and NROWS. Rows of the logical table become elements of the dataset; columns become fields of the compound datatype. This layout is simple and portable, but it is fundamentally row-oriented: every row occupies contiguous bytes, every column shares the same chunking, and changing a single column’s datatype, chunk shape, or compression filter requires rewriting the entire dataset.

The second influential idiom is PyTables, a Python package that has layered a rich query engine on top of HDF5. PyTables likewise stores a table as a single one-dimensional dataset of a compound type decorated with its own CLASS="TABLE", VERSION, TITLE, FIELD_N_FILL, NROWS, and PYTABLES_FORMAT_VERSION attributes. This adds a rich family of companion structures for indexing, in-kernel queries, and compression with Blosc. PyTables popularized the idea that a useful table format needs more than data bytes: it needs indexes, metadata, and conventions that let tools reason about the data.

The third and most recent influence is Anndata, which treats a table (dataframe) as an HDF5 group rather than a single compound dataset. Each column of the dataframe is stored as its own one-dimensional dataset inside that group. The group carries attributes that tell Anndata how to reassemble the columns into a dataframe — encoding-type="dataframe", encoding-version, column-order (a UTF-8 string array giving the column order), and _index (the name of the column that supplies row labels). Anndata extends this convention with dedicated encodings for nullable integers, nullable booleans, categoricals, sparse matrices, and more. This layout is column-oriented, and it is the closest existing HDF5 practice to what modern analytical engines expect.

1.2Why columnar, and why now¶

Row-oriented tables pack every value of every column together. That packing is ideal for use cases that scan whole rows (appending rows to a log, reading a few complete records by index) but it imposes three practical limits:

Uniform chunking and filtering. Every column in the table shares the same chunk shape and the same filter pipeline, because both are properties of the single compound dataset. A wide table that mixes a dense float column (well-served by shuffle + Zstd) with a high-cardinality string column (well-served by a dictionary encoding or Blosc bitshuffle) is forced to compromise.
Whole-row I/O for column queries. Selecting one column out of a hundred still reads every column’s bytes, because those bytes are interleaved within each chunk. Analytical workloads routinely scan a few columns of a wide table, and row orientation amplifies I/O proportional to row width.
Schema evolution. Adding or removing a column changes the compound datatype of the whole dataset, which in HDF5 terms means rewriting every chunk. Columnar layout makes schema evolution a matter of creating or deleting a sibling dataset.

Columnar formats such as Parquet, ORC, and Arrow Feather have become the lingua franca of analytical tabular data precisely because they decouple each column’s physical storage. HEP001 brings the same property to HDF5 while keeping everything the HDF5 ecosystem already has: a single container file, portable self-describing metadata, hierarchical groups, and lossless access to every tool in the HDF5 stack.

A decisive advantage of HDF5 over dedicated columnar formats is that tabular data does not have to live alone. For example, an HDF5 file can hold:

a table group with the experiment’s per-event observations,
a multidimensional dataset of raw sensor images addressed by those events,
a dense array of calibration coefficients indexed by detector channel,
and any number of nested groups carrying derived products.

Links, object references, and region references can tie rows of the table to slabs of the image cube without duplicating bytes. Analysts can query the table to identify events of interest and then dereference the rows into pixel-space regions in the same file, on the same storage, in a single API. Columnar tools and array tools meet in the middle.

1.3Scope and non-goals¶

HEP001 specifies:

the structure of a group that holds a column-oriented table,
the identifying attributes that let software recognize such a group,
how individual columns are represented as HDF5 datasets,
how columns whose row values are variable-length lists are represented as HDF5 groups, to arbitrary nesting depth,
how row-label indexes relate columns and the table group,
how search indexes accelerate queries over column values, including a normative chunk-min/max index and framework definitions for sorted-row, bitmap, and per-chunk Bloom-filter indexes.

HEP001 does not specify:

a query language or execution engine,
semantic conventions for domain-specific column units (outside the units / units_vocabulary attribute pair, which is descriptive only),
a table-discovery mechanism — locating every table group in a file requires a hierarchy traversal that inspects the CLASS attribute of each group if present, which files with very many groups may find costly; a future HEP MAY define an optional root-level manifest,
how tables are committed, versioned, or synchronized — those are the province of the storage layer and, perhaps, future HEPs.

2Conformance¶

The key words MUST, MUST NOT, SHOULD, SHOULD NOT, and MAY in this document are to be interpreted as described in RFC 2119 and RFC 8174 when, and only when, they appear in all capitals.

A file, group, or dataset is HEP001-conformant when it satisfies every MUST in the section that applies to it. A producer is HEP001-conformant when every table group it writes is conformant; a consumer is conformant when it can read any conformant table group without data loss.

2.1Datatype byte order¶

Except where this specification pins an exact datatype — the boolean datatype’s H5T_STD_I8LE base (§6) — integer and floating-point attributes and datasets MAY be stored in any byte order. HDF5 datatypes are self-describing, and the library converts on read. Datatype names such as uint64 in this document therefore constrain width and signedness, not byte order. The canonical byte representations used for Bloom-filter hashing (§11.7) are defined independently of storage order.

3Terminology¶

The following terms are used throughout this specification.

Table group: An HDF5 group that represents one column-oriented table. Identified by the CLASS attribute (see §7.1).

Dataset name: The name of the HDF5 hard link that connects an HDF5 dataset with its parent HDF5 group.
Column dataset: An HDF5 dataset of rank 1 that is a direct child of a table group and represents one column of the table. Datasets inside the reserved CATEGORIES and SEARCH_INDEXES subgroups, and datasets inside list column groups, are not column datasets. The dataset’s name is the column name.
List column: An HDF5 group that is a direct child of a table group, carries CLASS="LIST_COLUMN", and represents one column whose row values are variable-length lists. The group’s name is the column name. See List columns.
Column: A column dataset or a list column group. Where this specification says “column” without qualification, the statement applies to both.
Row index column: A column dataset referenced by the table group’s INDEX_COLUMNS attribute and which therefore supplies row labels for the table. Row index columns are otherwise indistinguishable from any other column dataset; the designation is made at the table-group level, not on the column itself.
Row: A position i in the half-open range [0, NROWS) (see §7.3) within every column dataset of the table group. Every column dataset MUST have the same first-dimension extent and that extent MUST be ≥ NROWS, so the same i refers to the same logical row everywhere.
NROWS: The number of logical rows currently in the table. A scalar uint64 attribute on the table group, defined in §7.3.
Categories dataset: An HDF5 dataset of rank 1 stored under the CATEGORIES child group of a table group that holds the label values backing one or more categorical columns. See Section 8.7.
Search index dataset: An HDF5 dataset stored under the SEARCH_INDEXES child group of a table group that accelerates queries over one or more column datasets. Each kind of search index is specified in Search indexes.

4Data model overview¶

A HEP001 table is an HDF5 group whose direct children are the table’s columns — rank-1 column datasets (one or more of which MAY be designated as row index columns via the table group’s INDEX_COLUMNS attribute) and optionally:

list column groups holding variable-length list values (List columns),
two reserved subgroups: CATEGORIES, with the label datasets that back categorical columns, and SEARCH_INDEXES, with query-acceleration structures.

The table’s authoritative row count lives in the table group’s NROWS attribute (see §7.3); every column dataset has the same first-dimension extent, and rows [0, NROWS) are the table’s data.

The rest of this document specifies each building block: the table group (The table group), column datasets (Column datasets), list columns (List columns), row index columns (Row index columns), and the four kinds of search-index dataset (Search indexes).

5Object references¶

Several HEP001 attributes link objects within a table group by HDF5 object reference: INDEX_COLUMNS (§7), CATEGORIES (§8.7), SEARCH_INDEX_LIST (§11), and VALUES (§11.6). Every such reference MUST use the HDF5 standard reference datatype H5T_STD_REF (introduced in HDF5 1.12). H5T_STD_REF is a unified datatype that can carry object, dataset-region, and attribute references (so future HEP revisions can introduce finer-grained linkages without a new on-disk reference format).

Producers MUST NOT write the deprecated object-reference datatype H5T_STD_REF_OBJ. A consumer MAY reject, as non-conformant, any HEP001 reference attribute whose datatype is not H5T_STD_REF.

6The boolean datatype¶

HDF5 has no native boolean datatype, and the wider HDF5 ecosystem has not converged on one encoding. HEP001 fixes a single, self-describing form so that boolean values are unambiguous on disk wherever they occur: in the attributes this specification calls boolean, in the MASK member datasets of list columns (§9.2), and in boolean columns (§8.8).

The HEP001 boolean datatype is an HDF5 enumerated datatype with:

base type H5T_STD_I8LE (signed 8-bit integer, little-endian), and
exactly two members, FALSE mapped to 0 and TRUE mapped to 1. Member names are case-sensitive.

In HDF5 DDL (as emitted by h5dump), the datatype is described as:

H5T_ENUM {
   H5T_STD_I8LE;
   "FALSE"    0;
   "TRUE"     1;
}

Producers MUST write every HEP001 boolean attribute and boolean-valued dataset with exactly this datatype, and MUST NOT store a HEP001 boolean as a plain integer, an H5T_BITFIELD, or a string. A consumer determines truth from the enumerated integer value (0 = false, 1 = true).

Consumers MUST additionally accept, as boolean, any enumeration datatype whose base type is a one-byte integer of either signedness and whose members are exactly FALSE = 0 and TRUE = 1. This tolerance accommodates writers that use native rather than standard base types (e.g., h5py); byte order is immaterial for a one-byte type. An enumeration datatype with any other member set is not a boolean.

7The table group¶

7.1Identification — the `CLASS` attribute¶

Every HEP001 table group MUST carry an attribute named CLASS with:

datatype: null-terminated 13-byte fixed-length ASCII string (exactly the length of the value below plus a NUL byte),
shape: scalar,
value: COLUMN_TABLE.

A consumer MUST identify a group as a HEP001 table group by, and only by, the presence of a CLASS attribute whose string value equals COLUMN_TABLE. A producer MUST NOT write CLASS="COLUMN_TABLE" attribute on any group that does not satisfy the rest of this specification.

The identification is strict-write, lenient-read. Producers MUST write the exact datatype above, but consumers SHOULD accept a CLASS attribute whose logical string value equals COLUMN_TABLE regardless of storage details: fixed-length strings of a larger size (null-terminated or null-padded per standard HDF5 conventions), variable-length strings, and either declared character set. Experience with earlier HDF5 conventions shows that third-party writers routinely vary these details. The same lenient-read rule applies to every HEP001 attribute whose value is a reserved ASCII token — CLASS on any group, KIND, and VERSION.

7.2The `VERSION` attribute¶

Every HEP001 table group MUST carry a scalar, fixed-length ASCII attribute named VERSION whose value is the HEP001 revision the table conforms to. Producers MUST size the attribute to hold the value being written. For this revision the value is "1.0".

HEP001 uses a two-component MAJOR.MINOR version with the major/minor semantics of Semantic Versioning: MAJOR increments on a backward-incompatible change to the data model (one an existing conformant consumer can no longer read), and MINOR on a backward-compatible addition. HEP001 omits SemVer’s third (PATCH) component deliberately since it would carry no actionable meaning. A consumer that prefers a SemVer-style triple MAY read an absent PATCH component as 0 — so "1.0" is equivalent to "1.0.0". Consumers MUST compare VERSION values numerically and MUST refuse to process a table whose MAJOR exceeds the highest MAJOR they implement.

7.3The `NROWS` attribute¶

Every HEP001 table group MUST carry a scalar NROWS attribute of datatype uint64 whose value is the number of logical rows currently in the table. NROWS is the table’s authoritative row count: rows [0, NROWS) of every column dataset are part of the table, and rows [NROWS, extent), when present, are reserved storage.

NROWS and a column dataset’s first-dimension extent are related but not equal in general. Every column’s extent MUST be ≥ NROWS (see §13), but it MAY exceed NROWS when a producer has preallocated space for future appends. A consumer MUST determine the table’s row count from NROWS and MUST NOT infer it from extent — doing so would silently include preallocated slots or post-crash residue as if they were table rows.

The attribute is borrowed from the long-established HDF5 Table and PyTables conventions, where it plays the same role. Centralizing the row count in one place — independent of any column’s storage state — gives producers a single-attribute commit point for atomic appends (see §12) and gives consumers a single place to look for the table’s size.

For a freshly created, empty table, NROWS = 0. Every column dataset’s first-dimension extent MUST be ≥ 0 (a zero-length column is permitted and is the natural form of a brand-new table).

7.4Optional table group attributes¶

The table group MAY carry the following attributes.

GENERATION: Scalar uint64. Identifies the current state of the table’s column data for the index validity check. REQUIRED whenever the table group contains any search-index dataset; MAY be omitted otherwise. See §12.2.
TITLE: Scalar fixed-length UTF-8 string. Human-readable title of the table, mirroring HDF5 Table and PyTables. Purely descriptive.
INDEX_COLUMNS: One-dimensional attribute of HDF5 object references whose elements point to the column datasets that serve as row labels for this table, in hierarchical order from outermost to innermost level. For example, a table indexed by (donor_id, sample_id, cell_id) writes INDEX_COLUMNS = [ref(donor_id), ref(sample_id), ref(cell_id)]. An empty array or absent attribute means the table has no row labels and rows are positional only. Every reference MUST resolve to a column dataset that is a direct child of the table group and MUST NOT be a null reference; a list column (List columns) MUST NOT be referenced, because lists have no HEP001-defined order. Row index columns apply to the table as a whole — every column in the table is labeled by them. See Row index columns.
column-order: One-dimensional fixed-length UTF-8 string attribute whose elements are the names of the table’s columns — column datasets and list columns alike — in their logical order. When present, it fully determines the column order presented to users; when absent, the logical column order is implementation-defined. Producers SHOULD write column-order whenever a table has more than one column. The attribute name uses a hyphen (not an underscore) to match Anndata.
_index: Scalar fixed-length UTF-8 string. The dataset name of the column that supplies the primary row labels for this table (for example, "row_id"). The name is borrowed from Anndata’s _index. When both INDEX_COLUMNS and _index are present, _index MUST equal the dataset name of the column referenced by INDEX_COLUMNS[0]. INDEX_COLUMNS is the authoritative row-label declaration; _index is a derived convenience written for Anndata affinity, and consumers MUST NOT prefer it over INDEX_COLUMNS when both are present.
encoding-type / encoding-version: Scalar fixed-length UTF-8 strings, both optional. These names are borrowed from Anndata’s DataFrame convention (§14.3). A producer MAY set encoding-type="dataframe" and encoding-version="0.2.0" if it separately wants Anndata software to attempt reading the group, but HEP001 neither requires nor interprets them and makes no guarantee that the result is a usable Anndata DataFrame (§16).
description: Scalar fixed-length UTF-8 string. Free-text description of the table’s contents. Longer and richer than TITLE; intended for documentation viewers.
units_vocabulary: Scalar fixed-length UTF-8 string. Names the vocabulary or authority that interprets units strings on columns of this table — for example "UDUNITS-2", "UCUM", "QUDT", or a URL. When present on the table group, it applies as a default to every column whose own units_vocabulary is absent.

7.5Placement of the table group¶

The table group MAY be located anywhere in an HDF5 file’s hierarchy. In the simplest case the root group of the file is the table group — the file holds one table and nothing else — and all columns live at the top level. Tables MAY also be nested under named groups to organize many tables, or sited beside multidimensional array datasets that they describe.

7.6Self-contained contents¶

A table group is the complete representation of a single column-oriented table. Every HDF5 object — group, dataset, named datatype, or link — that is a descendant of the table group MUST exist solely in service of the data model defined here.

The only objects permitted anywhere in the HDF5 hierarchy below a table group are:

the column datasets of the table (Column datasets), which MAY include row index columns designated by the table group’s INDEX_COLUMNS attribute (Row index columns);
list column groups and everything they contain (List columns);
the reserved CATEGORIES subgroup and everything it contains (Section 8.7);
the reserved SEARCH_INDEXES subgroup and everything it contains (Search indexes).

Any descendant of a table group that does not match one of the categories above is non-conformant. A producer MUST NOT place under a table group:

unrelated tables, including other HEP001 table groups;
multidimensional array datasets that are not derived from, or exclusively bound to, the columns of this table;
user-defined subgroups for provenance, schema, derived statistics, or any other auxiliary content not enumerated above.

Producers that wish to colocate such content with a table MUST do so by placing it as a sibling of the table group, or under an unrelated parent group elsewhere in the file. Object references, region references, and external links MAY be used to associate the table’s columns with that external content without violating this rule.

A consumer that encounters a descendant of a table group not described by this revision SHOULD emit a diagnostic identifying the offending HDF5 path. A consumer operating in strict-conformance mode MAY refuse to process the table; a consumer operating in lenient mode MAY ignore the offending descendant and continue.

Consumers MAY treat the table group as a closed, self-describing unit: copying, moving, renaming, deleting, or versioning the table group is guaranteed to act on the entire table and on nothing else.

8Column datasets¶

8.1Required properties¶

Each column of a HEP001 table — except list columns, which are stored as groups per List columns — MUST be stored as an HDF5 dataset that:

is a direct child of the table group,
has rank 1 shape,
has the same first-dimension extent as every other column dataset in the same table group, and that extent is ≥ NROWS (see §7.3 and §13).

The name of the HDF5 dataset is the column name. Any name acceptable as an HDF5 link name (UTF-8, excluding / and NUL) is permitted. Producers MUST NOT use any HEP001 reserved name (Section 14.2) as a column name. Producers SHOULD also avoid names that begin with an underscore, which are reserved for Anndata-aligned attribute names (_index) and may be claimed by future HEPs.

8.2Column discovery¶

The only HDF5 datasets that are direct children of a table group are its column datasets: categories datasets live one level down inside the CATEGORIES subgroup (§8.7), search-index datasets inside the SEARCH_INDEXES subgroup (§11), and a list column’s member datasets inside its list column group (§9). A consumer therefore enumerates a table’s columns as: the rank-1 datasets that are direct children of the table group, plus the direct-child groups whose CLASS attribute equals LIST_COLUMN. The CATEGORIES and SEARCH_INDEXES children carry no CLASS attribute and are skipped automatically.

When column-order (§7) is present it lists exactly these columns and fixes their order; when absent, the set of columns is still fully determined by this rule, and only their order is implementation-defined.

8.3Datatypes¶

The datatype of a column dataset MAY be any HDF5 datatype. Consumers that encounter a datatype they do not recognize SHOULD expose the column’s raw datatype instead of quietly ignoring it.

Two caveats apply:

Compound datatypes at the column level are permitted, but a table group is not a mechanism for storing a nested row-oriented table. When a compound-typed column is used, its fields MUST be logically atomic.
Variable-length datatypes (e.g. variable-length UTF-8 strings, ragged numeric arrays) are permitted but generally discouraged, as their storage characteristics are poorly suited to columnar access patterns. Producers SHOULD prefer fixed-length equivalents where possible. For ragged per-row sequences in particular, producers SHOULD use a list column (List columns) instead of a variable-length-typed column dataset; within list columns, variable-length datatypes are prohibited outright (§9.5).

8.4Chunking and filters¶

Because each column is its own HDF5 dataset, each column MAY independently select:

chunk shape (typically (N,) for N rows per column chunk),
dataset creation properties such as fill value, allocation time, and track-times,
the filter pipeline.

This per-column flexibility is the core motivation for HEP001 and is normative: producers MUST NOT require columns to share chunk shape or filters. Consumers MUST treat each column’s storage layout independently.

8.5Missing values (fill values)¶

A column dataset’s HDF5 fill value identifies rows whose value is missing. Producers MUST set the dataset’s fill value explicitly via the dataset creation property list (H5Pset_fill_value), placing the dataset into the H5D_FILL_VALUE_USER_DEFINED state, and MUST choose a fill value that lies outside the column’s logical value range. Boolean columns are the one exception: they have no out-of-domain value and MUST NOT declare a fill value (§8.8). A producer MAY declare that range explicitly with the two attributes valid_min and valid_max on the column dataset (each a scalar of the column’s element datatype). If present, the chosen fill value MUST lie strictly outside [valid_min, valid_max].

Consumers MUST retrieve the fill value — via H5Dget_create_plist followed by H5Pget_fill_value, using H5Pfill_value_defined to confirm the H5D_FILL_VALUE_USER_DEFINED state — and identify missing rows with the canonical missing-value test:

missing(value, fill_value) = isnan(fill_value) ? isnan(value) : value == fill_value

For every column whose fill value is not a NaN bit pattern — including every column whose datatype is not floating-point, and every column whose producer chose any of the recommended fill values in Table 1 — the isnan(fill_value) branch is always false and the test reduces to ordinary bit-equality value == fill_value. The same applies even to columns that contain no missing values — no row satisfies the test, and the column simply has no missing rows.

For floating-point columns with a NaN bit pattern as the fill value, the test reduces to isnan(value). IEEE 754 makes NaN != NaN, so a literal value == fill_value test would miss every fill-marked row in such columns; consumers MUST use the isnan(value) branch instead. HEP001 does not recommend NaN as a fill value — it conflates “the producer marked this row missing” with “the result of a floating-point computation was indeterminate” — but it permits NaN for producers who need a zero-cost round-trip with NaN-native ecosystems.

For producers that have no domain-specific constraint forcing a different choice, the table below lists recommended fill values for each datatype family.

Table 1:Recommended fill values

HDF5 datatype	Recommended fill value	Hex (canonical bit pattern)
`int8`	`-127`	`0x81`
`int16`	`-32767`	`0x8001`
`int32`	`-2147483647`	`0x80000001`
`int64`	`-9223372036854775807`	`0x8000000000000001`
`uint8`	`255`	`0xFF`
`uint16`	`65535`	`0xFFFF`
`uint32`	`4294967295`	`0xFFFFFFFF`
`uint64`	`18446744073709551615`	`0xFFFFFFFFFFFFFFFF`
`float32`	`9.9692099683868690e+36`	`0x7CF00000`
`float64`	`9.9692099683868690e+36`	`0x479E000000000000`
fixed string	`""`	n/a
vlen string	`""`	n/a
enumeration	`MISSING`	n/a

The recommended sentinels above are chosen as follows.

Integers. Signed-integer sentinels are INT*_MIN + 1 rather than INT*_MIN itself, leaving a one-value safety margin against operations that land on the type’s minimum (e.g., abs(INT*_MIN) is undefined behavior in C). Unsigned sentinels are the type’s maximum.

Floating point. Two choices are acceptable:

The recommended non-NaN sentinel 9.9692099683868690e+36. Exactly representable in both float32 and float64, and preserves bit-identity under width casts, so the equality branch of the canonical missing-value test works without rounding-tolerance gymnastics. This is the recommended choice for new tables that do not need byte-level round-tripping with NaN-native ecosystems.
Any NaN bit pattern (quiet, signaling, signed, with arbitrary payload). The canonical missing-value test then takes the isnan(value) branch. This choice is permitted but not recommended on its own merits; producers should use it when zero-cost interoperability with pandas, Anndata, NumPy, R, or other NaN-as-missing ecosystems matters more than disambiguating “missing” from “result of an indeterminate computation”.

Strings. The empty string is the recommended sentinel because it is rarely a meaningful value in practice.

Enumerations. The recommended sentinel is a designated enum member named MISSING. Producers using an enum column with missing values MUST include such a member in the enum type definition; the integer code backing the MISSING member then serves as the column’s fill value.

For datatypes not in the table:

float16 is too narrow for a generic sentinel.
Boolean columns cannot represent a missing sentinel alongside their two valid values and declare no fill value at all. For nullable boolean data, use one of the two forms defined in §8.8 (a three-member enumeration with MISSING, RECOMMENDED, or a uint8 column with fill 255).

Producers whose column domain includes any of the recommended sentinels above MUST choose a different fill value via H5Pset_fill_value. For columns with a natural numeric range (integer and floating-point columns), producers MUST also declare that range via valid_min and valid_max and choose the fill outside it. For columns without a natural numeric range (strings, opaque), the alternative fill value alone constitutes the override; no additional attribute is required.

Full-domain columns¶

The sentinel scheme has a limit: a column whose logical domain spans every representable value of its datatype — a uint8 column that legitimately uses all 256 values, or an int64 column of arbitrary 64-bit identifiers or hashes — has no out-of-domain value left to serve as a fill sentinel, and therefore cannot represent missing rows under this revision. A producer of such a column MUST either use a wider datatype whose additional range provides a sentinel, or declare no missing-row semantics for the column (every row position in [0, NROWS) holds a value). The reserved mask mechanism below is the intended future remedy.

Reserved: the `MASK` column attribute¶

A future revision of this HEP is expected to define an explicit validity-mask mechanism for column datasets, covering the full-domain case above. So that tools do not invent incompatible encodings in the interim, this revision reserves the attribute name MASK on column datasets for that purpose. The intended shape of the mechanism, stated here for orientation and not as normative specification: the attribute holds an HDF5 object reference to a per-row validity dataset of the HEP001 boolean datatype (§6) with first-dimension extent ≥ NROWS, in which FALSE marks the row missing — element-for-element the semantics that the MASK member dataset already has inside list columns (§9.2) — and, when present, it takes precedence over the canonical missing-value test for the column that carries it.

Producers conforming to this revision MUST NOT write a MASK attribute on a column dataset. A consumer that encounters one SHOULD treat the column as governed by a later revision of this HEP: it SHOULD NOT assume that the fill-value test alone identifies the column’s missing rows.

8.6Column attributes¶

A column dataset MAY carry any of the following attributes.

SEARCH_INDEX_LIST: One-dimensional array of HDF5 object references. Each reference points to a search-index dataset (see §11) in the SEARCH_INDEXES subgroup that accelerates queries on this column.
CATEGORIES: Scalar HDF5 object reference. Used only for categorical columns. Points to the dataset that holds the categorical values (see §8.7).
valid_min / valid_max: Scalar attributes of the same datatype as the column, specifying the minimum and maximum range of the column’s values. See §8.5.
units: Scalar fixed-length UTF-8 string. Physical units of the column’s values. Absence of units implies dimensionless data. Units are interpreted according to units_vocabulary (on the column, or inherited from the table group).
units_vocabulary: Scalar fixed-length UTF-8 string. Identifies the units vocabulary that interprets units. When present on a column, it overrides the table group’s units_vocabulary for that column. MAY be a short name ("UDUNITS-2") or a URL.
description: Scalar fixed-length UTF-8 string. Plain-text description of the column’s contents, provenance, or semantics.

8.7Categorical columns¶

A categorical column stores integer codes that index into a separate categories dataset holding the actual label values. The code at row i is the zero-based position of that row’s label in the categories dataset.

The `CATEGORIES` group¶

A table group MAY contain a direct child group named CATEGORIES. When present, it MUST hold every categories dataset for the table, and no other objects. It carries no required attributes of its own. Categories datasets in CATEGORIES MAY have any name; the binding between a column and its categories dataset is the column’s CATEGORIES object reference (§5), never a parsed name.

Categorical column requirements¶

A categorical column MUST:

Have an integer datatype (any width, signed or unsigned). The column’s missing value (the dataset’s fill value) denotes a missing category.
Carry a scalar CATEGORIES attribute whose value is an HDF5 object reference resolving to a categories dataset in the table group’s CATEGORIES subgroup.

A categories dataset MUST:

Live directly under the table group’s CATEGORIES subgroup.
Have rank 1, with any datatype appropriate to the label values.

A categories dataset MAY:

Carry a scalar boolean attribute ordered (matching Anndata’s ordered categoricals), encoded per §6. Producers MUST set ordered to true exactly when the order of entries in the categories dataset is semantically meaningful.
Back more than one categorical column. Several categorical columns that share a common label set MAY reference the same categories dataset through their CATEGORIES attributes; producers need not duplicate a shared code book.

A categories dataset is not a column dataset: it does not count toward the table’s columns, and it MUST NOT appear in the table group’s column-order (§13).

8.8Boolean columns¶

A boolean column is a column dataset whose datatype is the HEP001 boolean datatype §6. The producer-strict, consumer-lenient rules defined there apply: producers MUST write exactly that datatype; consumers MUST accept the tolerated one-byte variants. An enumeration datatype with any other member set is not a boolean column and is governed by the ordinary rules for enumeration columns.

Values¶

Every element of a boolean column at a row position in [0, NROWS) MUST be 0 or 1. A boolean column holding any other value at those positions is non-conformant, and consumers MUST NOT interpret such a value as either FALSE or TRUE: silent coercion would let two conformant consumers return different results for the same query and would make the canonical byte representation of §11.7 ambiguous. Rows in [NROWS, extent) are reserved storage and exempt (§7.3).

Missing values¶

A boolean column cannot represent missing values: both values of its domain are meaningful, so no in-domain sentinel exists. A boolean column MUST NOT declare a user-defined fill value, and the requirements of §8.5 do not apply to it — boolean columns are the one column datatype exempt from that section’s mandatory fill value.

A producer that needs a nullable boolean MUST use one of the following two forms instead. Neither is a boolean column.

RECOMMENDED: an enumeration column with exactly three members — FALSE = 0, TRUE = 1, MISSING = 2 — declaring the integer code of MISSING as the fill value, per the enumeration convention of §8.5. This form is self-describing: the member names preserve the column’s boolean semantics for any consumer.
An integer column of datatype uint8 with values 0 and 1 and a declared fill value outside {0, 1} (255 RECOMMENDED, matching the recommended uint8 fill of Table 1), for pipelines that prefer plain integers at the cost of self-description.

Interaction with search indexes¶

For the purposes of §11:

Ordering (SORTED_ROWS, CHUNK_MINMAX): boolean values order by their integer codes; FALSE sorts before TRUE.
CHUNK_MINMAX: the min and max fields use the column’s datatype. Min/max pruning over a two-value domain is rarely useful; producers SHOULD prefer BITMAP for boolean columns.
CHUNK_BLOOM: the canonical byte representation of a boolean value is a single byte, 0x00 for FALSE and 0x01 for TRUE (§11.7).
BITMAP: permitted; the accompanying values dataset holds at most two entries.

9List columns¶

A list column stores a variable-length list of values in each row — list<float32>, list<utf8>, list<list<int16>>, and so on. Unlike every other column in this specification, a list column is not a single rank-1 dataset: it is an HDF5 group that is a direct child of the table group. The group’s link name is the column name, and the member datasets inside the group together encode the rows’ lists.

The encoding is the offsets layout of the Apache Arrow columnar format. All elements of all rows are stored back-to-back in a flattened VALUES member, in row order, and a monotonic OFFSETS dataset records each row’s slice: row i’s list occupies elements [OFFSETS[i], OFFSETS[i+1]) of the VALUES member. Access is positional and O(1) per row, and a VALUES dataset is an ordinary HDF5 dataset with its own datatype, chunk shape, and filter pipeline. The same per-column storage independence that motivates HEP001 extends to list elements. Because the VALUES member MAY itself be another list encoding, lists nest to arbitrary depth: JSON-style arrays of arrays of any depth fit naturally, provided the innermost elements share one datatype.

9.1Identification¶

Every list column group MUST carry the following two attributes:

CLASS: Scalar, null-terminated fixed-length ASCII string attribute with value LIST_COLUMN. A consumer MUST identify a list column as a direct child group of a table group whose CLASS attribute equals LIST_COLUMN. Groups deeper inside a list column MAY also carry CLASS="LIST_COLUMN" (nested lists, §9.2); they are part of their outermost list column’s encoding and are not themselves columns of the table.
KIND: Scalar, null-terminated fixed-length ASCII string attribute naming the storage method used inside the group. The only value defined by this revision is OFFSETS, specified in this section. Future revisions MAY register additional values. A consumer that encounters a KIND it does not implement MUST NOT silently drop the column; it SHOULD surface the column as present but unreadable.

A producer MUST NOT write CLASS="LIST_COLUMN" on any group that does not satisfy the rest of this section.

9.2Members of a list column group¶

A KIND="OFFSETS" list column group contains the following members, and no other objects. The member dataset names are reserved names (Section 14.2).

OFFSETS

REQUIRED. A rank-1 dataset of datatype uint64. OFFSETS[0] MUST be 0, and values MUST be monotonically non-decreasing over positions [0, L], where L is the number of entries at this level (§9.3). Entry i occupies elements [OFFSETS[i], OFFSETS[i+1]) of the VALUES member; an empty list has OFFSETS[i+1] = OFFSETS[i]. The first-dimension extent MUST be ≥ L + 1; positions beyond L are reserved storage (§12).

VALUES

REQUIRED. The flattened elements of all entries, in entry order. Exactly one of:

a rank-1 HDF5 dataset — the leaf case. The element datatype MAY be any datatype permitted for a column dataset except variable-length datatypes (§9.5);
a group with CLASS="LIST_COLUMN" and KIND="OFFSETS" — the elements are themselves lists (nested lists);
a group with CLASS="STRING_VALUES" — the elements are variable-length UTF-8 strings (§9.4).

MASK

OPTIONAL. A rank-1 dataset of the boolean datatype of §6, with first-dimension extent ≥ L. MASK[i] = FALSE declares entry i null (missing); MASK[i] = TRUE declares it present. When MASK is absent, every entry at this level is present. For a null entry the producer MUST write OFFSETS[i+1] = OFFSETS[i], so that null and empty entries both occupy zero elements of VALUES and only MASK distinguishes them.

Each member dataset MAY independently select its chunk shape, dataset creation properties, and filter pipeline, per the same rule that governs column datasets. Producers SHOULD NOT rely on fill values of OFFSETS or MASK datasets; missingness at each level is expressed only as specified here.

9.3Levels, entries, and nesting¶

The entries of the top level of a list column are the table’s rows: L = NROWS, and the same [0, NROWS) / reserved-tail semantics that govern column datasets (§7.3) govern the top-level OFFSETS and MASK.

When a VALUES member is itself a list encoding (a nested LIST_COLUMN or a STRING_VALUES group), the entries of that nested level are the elements of its parent level: its entry count is L_nested = OFFSETS_parent[L_parent]. Its own OFFSETS extent MUST be ≥ L_nested + 1 and its MASK extent, when present, ≥ L_nested. This rule applies recursively to any depth. A nested MASK distinguishes a null inner list from an empty inner list at that level.

Missing values at the three structural positions are therefore expressed as: a null list by the MASK of the level above the list; a null string element by the MASK of the STRING_VALUES group; and a missing leaf element by the fill value of the leaf VALUES dataset, using the canonical missing-value test of §8.5 unchanged. The leaf VALUES dataset MAY carry valid_min / valid_max per §8.5.

9.4String elements — the `STRING_VALUES` group¶

Variable-length string elements are stored without HDF5 variable-length datatypes, as a second offsets level over a byte buffer. A group with CLASS="STRING_VALUES" (scalar, null-terminated fixed-length ASCII string attribute) contains exactly:

OFFSETS: REQUIRED. As in §9.2: rank-1 uint64, OFFSETS[0] = 0, monotonic, extent ≥ L + 1 for L entries. Entry j is the byte range [OFFSETS[j], OFFSETS[j+1]) of CHARS.
CHARS: REQUIRED. A rank-1 dataset of datatype uint8 holding the UTF-8 encoding of all entries, back to back — with no byte-order mark and no Unicode normalization (no NFC, NFD, NFKC, or NFKD conversion), matching the string rules used elsewhere in this specification. Because the element type is uint8, the buffer passes through the filter pipeline and compresses like any other dataset.
MASK: OPTIONAL. As in §9.2; distinguishes a null string entry from an empty one.

Producers whose string elements have a known maximum byte length SHOULD consider the simpler leaf alternative: a VALUES dataset of a fixed-length UTF-8 string datatype sized to that bound (one UTF-8 code point can occupy up to four bytes). Fixed-length string elements pass through the filter pipeline directly and need no STRING_VALUES group; the empty-string missing-value convention of §8.5 applies to them unchanged.

9.5No variable-length datatypes¶

A producer MUST NOT use any HDF5 variable-length datatype — variable-length strings or variable-length sequences of any base type — anywhere below a list column group. Every conformant list column subtree is therefore free of global-heap storage.

This rule is stricter than the SHOULD-level discouragement that applies to column datasets, and it is deliberate: list columns exist to make variable-length data fast, and variable-length datatypes are not. Their element bytes live on the HDF5 global heap, outside the dataset’s chunks, so the filter pipeline compresses only the heap references while the data itself is stored uncompressed with per-object heap overhead. Heap access defeats direct chunk I/O and cloud-optimized readers. Parallel HDF5 collective I/O cannot write variable-length data. Heap space freed by rewrites is not reclaimed short of h5repack. The OFFSETS + CHARS encoding of §9.4 and fixed-length element datatypes together cover the same use cases without any of these costs.

9.6List column attributes¶

A list column group MAY carry the descriptive attributes description, units, and units_vocabulary with the same meanings they have on column datasets; units describes the leaf elements. A list column group MUST NOT carry SEARCH_INDEX_LIST — this revision defines no search indexes over list columns; a future revision MAY. A list column MUST NOT be referenced by the table group’s INDEX_COLUMNS attribute — lists have no HEP001-defined order, so they cannot serve as row labels. A list column SHOULD appear in column-order by name, like any other column.

9.7Reading a list column¶

To read row i of a KIND="OFFSETS" list column, a consumer:

reads MASK[i] if MASK is present FALSE yields a null list;
reads OFFSETS[i] and OFFSETS[i+1]; equal values with a present (or absent) mask yield an empty list;
reads elements [OFFSETS[i], OFFSETS[i+1]) of VALUES, recursing per level when VALUES is a group.

Since step 1 matters only when the slice is empty, consumers MAY defer it and typical rows cost one OFFSETS read plus one VALUES read — the same two dependent reads that any variable-length encoding requires, with the first falling on a small, cache-friendly dataset.

10Row index columns¶

A row index column is a column dataset referenced by the table group’s INDEX_COLUMNS attribute (see §7). Row index columns supply row labels for the table as a whole — every column in the table is labeled by every row index column. They are ordinary column datasets in every other respect, and they SHOULD also appear in column-order like any other column.

10.1Hierarchy¶

When INDEX_COLUMNS contains more than one reference, the order is the row-label hierarchy from outermost to innermost level. For example, INDEX_COLUMNS = [ref(donor_id), ref(sample_id), ref(cell_id)] declares a three-level row index in which donor_id is the outermost grouping and cell_id is the innermost row identifier.

10.2Typical uses¶

Single row index. The common case: one column (often a string of sample IDs, or an unsigned-integer ordinal) supplies row labels for the entire table.
Hierarchical row index. A small number of tables have a meaningful row-label hierarchy — for example, donor → sample → cell in single-cell genomics, or year → quarter → ticker in financial time series. INDEX_COLUMNS lists the level columns in order.
No row index. A table whose rows are identified solely by their position (the N-th row is “row N”) SHOULD omit INDEX_COLUMNS entirely. Producers MAY equivalently write INDEX_COLUMNS as an empty 1-D object-reference array; consumers MUST treat the two forms as semantically identical.

11Search indexes¶

Search indexes accelerate queries over column values. They do not change the logical table; they are derivative, recomputable data. A conformant consumer MAY ignore any or all search indexes and still return correct answers, only more slowly.

11.1The `SEARCH_INDEXES` group¶

A table group MAY contain a direct child group named SEARCH_INDEXES. When present, it MUST hold every search-index dataset for the table, together with any accompanying datasets those search indexes require and no other objects. It carries no required attributes of its own. Datasets in SEARCH_INDEXES MAY have any name.

A search-index dataset is distinguished from an accompanying dataset by the KIND attribute (§11.3): every search-index dataset MUST carry KIND, and an accompanying dataset MUST NOT carry KIND.

11.2Linking columns to search indexes¶

Each column dataset that benefits from a search index MUST reference that search index from its own SEARCH_INDEX_LIST attribute — a 1-D array of HDF5 object references to search-index datasets in the SEARCH_INDEXES subgroup. The column-side attribute is the only linkage; search-index datasets do not carry a back-pointer to the columns they accelerate. To determine the column that a given search-index dataset applies to, scan the column datasets of the table group and identify the one whose SEARCH_INDEX_LIST references that search-index dataset.

11.3Common per-index attributes¶

Every search-index dataset MUST carry a scalar fixed-length ASCII attribute KIND whose value is one of the strings defined below:

`KIND` value	Purpose	Defined in
`CHUNK_MINMAX`	Per-chunk min and max of an orderable column	§11.4
`SORTED_ROWS`	Row-position permutation of a column	§11.5
`BITMAP`	Per-value bitmap of a low-cardinality col.	§11.6
`CHUNK_BLOOM`	Per-chunk Bloom filter of a column	§11.7

Future HEPs MAY register additional KIND values. Consumers MUST treat unknown KIND values as “ignore this search index”.

Every search-index dataset MUST also carry the two validity-token attributes SOURCE_GENERATION and SOURCE_NROWS (§12.2). A consumer MUST evaluate the validity check defined there before using any search index.

The shapes of search-index datasets grow with the table: CHUNK_MINMAX and CHUNK_BLOOM track the source column’s data-bearing chunk count, SORTED_ROWS and BITMAP track NROWS. Producers SHOULD therefore create search-index datasets chunked, with the growing dimension unlimited, so appends can extend them in place; a producer MUST NOT instead delete and recreate an index dataset on each update.

A search-index dataset MAY also carry a description attribute (scalar fixed-length UTF-8 string), per the descriptive-annotation convention used elsewhere in this spec (see Reserved names, rule 4). Producers SHOULD use description to record provenance — the timestamp of index construction, the producer software and version, and any hyperparameters not captured by the index family’s own attributes. Consumers MAY ignore description for query-execution purposes; it is purely informational.

11.4Chunk min/max search index (`KIND = CHUNK_MINMAX`)¶

A chunk min/max index accelerates range and equality predicates over an orderable column by letting the engine skip chunks whose value range does not overlap the predicate. The column’s datatype MUST have a HEP001-defined order — the same orders enumerated for SORTED_ROWS under Ordering in §11.5 (integers, floating-point, boolean, strings, opaque, and enumerations) — and min and max are computed under that order. The datatypes that SORTED_ROWS excludes for lack of a defined order (object and region references, compound, array, and variable-length-array datatypes) likewise MUST NOT carry a CHUNK_MINMAX index.

Shape: The search-index dataset is 1-D with length equal to the number of chunks of the source column dataset that contain logical-table rows:

ceil(NROWS / chunk_length) for a chunked column,
1 for a contiguous column (or 0 when NROWS = 0).

Chunks lying entirely in the column’s preallocated tail ([NROWS, extent), see §7.3) are not indexed.

Datatype: An HDF5 compound datatype with the following fields, in declaration order:

min — same datatype as the source column’s element type.
max — same datatype as the source column’s element type.
nan_count — uint64. The number of IEEE 754 NaN values in the chunk, regardless of whether NaN is the column’s fill value. For non-floating-point columns this field MUST be present and set to 0.
fill_count — uint64. The number of elements in the chunk that the canonical missing-value test (§8.5) classifies as missing. When the column’s fill value is itself a NaN bit pattern, every NaN element is missing by definition, and fill_count equals nan_count for that chunk; this overlap is intentional and consumers MAY rely on fill_count alone as the chunk’s missing-row count regardless of the column’s fill choice.
n — uint64. The number of logical rows (i.e., rows in [0, NROWS); see §7.3) covered by this chunk. For every chunk other than the last, n equals the column’s chunk length; for the last data-bearing chunk, n MAY be strictly less than the chunk length when NROWS is not a multiple of it.

Semantics: min and max are computed over only those elements of the chunk that the canonical missing-value test (§8.5) classifies as non-missing, and that are themselves orderable. For floating-point columns this means: NaN values are excluded (because IEEE 754 does not order them, regardless of whether NaN is the column’s fill value), and elements that match the column’s non-NaN fill value (if any) are excluded. For integer and other orderable types, only elements equal to the column’s fill value are excluded. When the chunk has no non-missing, orderable elements (fill_count + nan_count == n for floating-point columns, or fill_count == n for other orderable types), min and max MUST be set to the column’s fill value. In that case min and max are placeholders with no semantic meaning: consumers MUST recognize such chunks from the fill_count, nan_count, and n fields and MUST NOT use the placeholder values as bounds in pruning decisions.

Applicability: Each CHUNK_MINMAX search-index dataset applies to exactly one column, identified by the column whose SEARCH_INDEX_LIST references it. The column’s HDF5 datatype MUST have a HEP001-defined order, as enumerated for SORTED_ROWS under Ordering (§11.5); otherwise no CHUNK_MINMAX index is permitted. A producer MAY build separate CHUNK_MINMAX indexes for several columns, but a single search-index dataset MUST NOT cover multiple columns because chunks of different columns are independent.

Additional attributes on the search-index dataset:

KIND — "CHUNK_MINMAX" (see §11.3).

All other per-index data lives in the compound datatype’s fields (min, max, nan_count, fill_count, n); these are HDF5 datatype fields, not HDF5 attributes.

11.5Sorted-row permutation index (`KIND = SORTED_ROWS`)¶

A sorted-row index stores row positions in sorted order of a column’s values, enabling binary search and range scans without reading the full column.

Shape: 1-D, length equal to NROWS (see §7.3). Rows of the source column lying in the preallocated tail [NROWS, extent) are not part of the permutation.

Datatype: An unsigned integer wide enough to address every row of the source column (typically uint64).

Semantics: Element i of the index is the row position r such that, under the ordering defined below, the i-th rank of the column’s values lives at row r. Ties between rows with identical values MUST be broken by increasing r, so the permutation is total and deterministic.

Ordering: A SORTED_ROWS index MUST only be built over a column whose HDF5 datatype has a HEP001-defined order, as enumerated below:

Signed and unsigned integers (any width): standard arithmetic order.
Floating-point values (float16, float32, float64): IEEE 754 numerical order over finite values and the two infinities. Negative zero MUST compare equal to positive zero. NaN values are not ordered; rows whose value is NaN MUST be placed at the end of the permutation, in increasing r order, and the nan_tail_length attribute MUST record the count. The NaN tail and the fill tail are always disjoint by construction: a row is placed in the NaN tail if its value is NaN, and otherwise in the fill tail if its value equals a non-NaN fill. When the column’s fill value is itself NaN, every missing row is a NaN row and is placed in the NaN tail; fill_tail_length is then 0, and nan_tail_length equals the column’s total missing-row count.
Boolean values (boolean columns, §8.8): ordered by integer code; FALSE (0) sorts before TRUE (1).
Fixed- and variable-length strings: lexicographic comparison over the UTF-8 byte sequence — i.e., byte-wise, with no byte-order mark and no Unicode normalization (no NFC, NFD, NFKC, or NFKD conversion is applied). For HDF5 fixed-length strings, the column’s storage-padding bytes — NUL bytes (0x00) for H5T_STR_NULLTERM and H5T_STR_NULLPAD, space bytes (0x20) for H5T_STR_SPACEPAD — MUST be stripped from the trailing end of each string before comparison, so that the same logical string sorts identically whether stored fixed- or variable-length. Strings whose declared HDF5 character set is H5T_CSET_ASCII MUST be ordered as if they were UTF-8 (ASCII is a strict subset). HEP001 does not specify locale-sensitive collation (e.g., POSIX strcoll, ICU UCA); byte-wise comparison is the only conformant rule because it is deterministic across implementations, platforms, and runtime locales.
Opaque (H5T_OPAQUE) values: byte-wise lexicographic comparison over the raw bytes of the value; the opaque tag, if any, is not part of the comparison.
Enum datatypes: ordered by the underlying integer codes, using the integer rule above.

The following datatypes do not have a defined sorting order, so a SORTED_ROWS index MUST NOT be built on them:

HDF5 object and region references (no canonical order over references);
compound datatypes (a future HEP MAY register a canonical multi-field ordering);
array and variable-length-array datatypes.

Rows whose value matches a non-NaN column fill value under the canonical missing-value test (§8.5) MUST appear immediately before the NaN tail (if any), in increasing r order, and the fill_tail_length attribute MUST record the count. For datatypes that have no NaN concept, the NaN tail is empty (nan_tail_length = 0) and the fill-tail rows appear at the very end of the permutation. When the column’s fill value is itself NaN, all missing rows are NaN rows and are placed in the NaN tail (see the floating-point ordering rule above); the fill tail is then empty (fill_tail_length = 0).

Additional attributes:

KIND — "SORTED_ROWS".
nan_tail_length, fill_tail_length — scalar uint64. Both MUST be present; either MAY be 0.
ordered — scalar boolean (§6). MUST be true for SORTED_ROWS; reserved for future indexes that permit partial orderings.

Applicability: Each SORTED_ROWS search-index dataset applies to exactly one column, identified by the column whose SEARCH_INDEX_LIST references it. The column’s HDF5 datatype MUST have a HEP001-defined order, as enumerated under Ordering above; otherwise no SORTED_ROWS index is permitted.

11.6Bitmap index (`KIND = BITMAP`)¶

A bitmap index accelerates equality predicates on low-cardinality columns.

Shape: 2-D of shape (K, ceil(NROWS / 8)), where K is the number of distinct values (or categories) indexed and NROWS is the table’s row count (see §7.3). Rows of the source column lying in the preallocated tail [NROWS, extent) are not indexed.

Datatype: uint8. Bit r % 8 (where bit 0 is the byte’s least significant bit) of byte r / 8 of row k is set if the column’s value at row r equals the k-th indexed value. Because the storage element is uint8, HDF5 performs no byte swapping on read or write — the bytes on disk are exactly the bytes the producer wrote. When NROWS is not a multiple of 8, the bits at positions ≥ NROWS in each row’s final byte are padding: producers MUST write them as 0, and consumers MUST ignore them regardless of their value.

Accompanying values dataset: A sibling 1-D dataset, under SEARCH_INDEXES, holds the K indexed values in the same datatype as the source column. Its name is linked from the bitmap via a scalar VALUES object-reference attribute. This values dataset is an accompanying dataset, not a search-index dataset: it MUST NOT carry a KIND attribute (see §11).

Additional attributes on the bitmap dataset:

KIND — "BITMAP".
VALUES — scalar HDF5 object reference to the values dataset.
ordered — scalar boolean (§6). When true, the entries in the values dataset (linked via VALUES) are listed in a semantically meaningful order, for example, a numerically-sorted set of distinct values or an ordinal category sequence such as ["low", "medium", "high"]. The bitmap’s k-th row corresponds to the k-th entry of the values dataset under that order. When false or absent, the order of the values dataset is arbitrary (typically insertion order) and consumers MUST NOT infer any semantic ordering from it.
exhaustive — scalar boolean (§6). When true, the values dataset enumerates every distinct non-missing value that occurs in rows [0, NROWS) of the source column, so a query value absent from the values dataset provably matches zero rows. When false or absent, the enumeration MAY be partial — for example, only the most frequent values — and consumers MUST treat a query value absent from the values dataset as unindexed (falling back to a scan), not as proof of absence.

Applicability: Each BITMAP search-index dataset applies to exactly one column, identified by the column whose SEARCH_INDEX_LIST references it.

11.7Per-chunk Bloom filter index (`KIND = CHUNK_BLOOM`)¶

A per-chunk Bloom filter accelerates equality predicates on high-cardinality columns by giving a fast negative answer for chunks that provably do not contain the queried value.

Shape: 2-D of shape (n_chunks, m_bytes), where n_chunks is the number of chunks of the source column that contain logical-table rows (ceil(NROWS / chunk_length) for a chunked column, 1 for a contiguous column, or 0 when NROWS = 0; see §7.3) and m_bytes is the Bloom-filter byte length per chunk (constant across chunks). Chunks lying entirely in the column’s preallocated tail [NROWS, extent) are not indexed.

Datatype: uint8. Each row is the packed bit array of one chunk’s Bloom filter. Because the storage element is uint8, HDF5 performs no byte swapping on read or write — the bytes on disk are exactly the bytes the producer wrote.

Bit packing: Filter bit g (where 0 ≤ g < m_bits) is stored at bit position g % 8 (where bit 0 is the byte’s least significant bit) of byte g / 8 of the chunk’s row. Equivalently, setting filter bit g is row[g >> 3] |= (uint8_t)1 << (g & 7). m_bits MUST be a multiple of 8, so that m_bytes = m_bits / 8 is exact.

Hash scheme: HEP001 prescribes — for interoperability — Kirsch–Mitzenmacher double hashing h_i(x) = (h_a(x) + i * h_b(x)) mod (8 * m_bytes) for i = 0 … k − 1. Both h_a and h_b come from a single invocation of MurmurHash3_x64_128 (the 128-bit, 64-bit-tuned variant of MurmurHash3) over the value’s canonical byte representation (see below), seeded with the value of the seed attribute. The low 64 bits of the 128-bit output become h_a; the high 64 bits become h_b. The number of hash functions k is stored as an attribute.

Canonical byte representation: Bloom-filter hashes MUST be computed over a column value’s canonical byte representation, defined here. The canonical form is independent of how the column is stored on disk: a column written in big-endian MUST be transcoded to its canonical form before hashing, and a consumer evaluating a query MUST canonicalize the query value identically before testing the filter.

Signed integers (int8, int16, int32, int64): the value’s two’s-complement representation in the column’s storage width, packed little-endian. An int8 is one byte; an int64 is exactly eight.
Unsigned integers (uint8 … uint64): the value’s unsigned representation in the column’s storage width, packed little-endian.
Floating-point values (float16, float32, float64): the value’s IEEE 754 binary encoding at the column’s storage width, packed little-endian. NaN values MUST NOT be inserted into a Bloom filter — different NaN bit patterns would yield different filter bits and break interoperability — and consumers MUST NOT query for NaN against a CHUNK_BLOOM index. The rule applies whether NaN is a real-data value in the column or the column’s chosen fill value: in the latter case, NaN elements are missing values, and missing values are by convention excluded from Bloom-filter membership testing anyway. Producers MUST normalize negative zero to positive zero before hashing.
Boolean values (boolean columns, §8.8): a single byte, 0x00 for FALSE or 0x01 for TRUE.
Enumeration datatypes other than boolean columns (covered above): the value’s underlying integer code in the column’s storage width, packed little-endian, following the signed or unsigned integer rule above according to the base type. Codes are canonicalized against the column’s own enumeration definition — the same definition a consumer uses to resolve a queried member name to a code — so differing code assignments for the same member names across files are harmless. An integer code that serves as the column’s fill value (for example, a MISSING member per §8.5) denotes a missing value: it is excluded from Bloom-filter membership per the general missing-value convention, and consumers MUST NOT query for it.
Fixed- and variable-length strings: the string’s UTF-8 byte sequence, with no byte-order mark and no Unicode normalization (no NFC, NFD, NFKC, or NFKD conversion is applied). For HDF5 fixed-length strings, the column’s storage-padding bytes — NUL bytes (0x00) for H5T_STR_NULLTERM and H5T_STR_NULLPAD, space bytes (0x20) for H5T_STR_SPACEPAD — MUST be stripped from the trailing end of each string before hashing, so that the same logical string hashes identically regardless of the column’s declared padding mode. Strings whose declared HDF5 character set is H5T_CSET_ASCII MUST be hashed as if they were UTF-8 (ASCII is a strict subset).
Opaque (H5T_OPAQUE) values: the raw bytes of the value in column order; the opaque tag, if any, is not part of the hashed bytes.
HDF5 object and region references: out of scope for this revision. Producers MUST NOT build a CHUNK_BLOOM index over a reference-typed column.
Compound, array, and variable-length-array datatypes: out of scope for this revision. Producers MUST NOT build a CHUNK_BLOOM index over such columns. A future HEP MAY register canonical encodings for these cases.

Additional attributes:

KIND — "CHUNK_BLOOM".
k — scalar uint16. The number of hash functions.
m_bits — scalar uint64. Equal to 8 * m_bytes; stored explicitly for clarity.
hash_family — scalar fixed-length ASCII string; for this revision MUST be "murmur3_x64_128_double".
seed — scalar uint32. The seed passed to MurmurHash3_x64_128, whose reference implementation accepts a 32-bit seed. Default 0. Producers MAY change the seed to mitigate adversarial inputs; consumers MUST read the seed from this attribute rather than assuming 0.

Applicability: Each CHUNK_BLOOM search-index dataset applies to exactly one column, identified by the column whose SEARCH_INDEX_LIST references it. The column’s HDF5 datatype MUST belong to one of the kinds enumerated under Canonical byte representation; otherwise no CHUNK_BLOOM index is permitted.

12Writing and appending data¶

This section specifies how producers add, remove, or rewrite rows of a HEP001 table and how consumers interpret the table during and after those operations. The contract is anchored on the table group’s NROWS attribute (§7.3).

12.1How consumers interpret `NROWS`¶

NROWS is the authoritative count of rows currently in the table. A consumer MUST treat rows [0, NROWS) of every column dataset as the table’s data and MUST ignore rows [NROWS, extent) of any column dataset, even when those rows hold values that are not the column’s fill value. The tail is reserved storage, not data; its contents have no semantic meaning under HEP001 and MAY contain arbitrary bytes left behind by a previous write, a previous truncation, or HDF5’s own fill-value mechanism.

The same cutoff applies to search indexes. A consumer MUST consult only those index entries that describe rows or chunks within [0, NROWS). Tail entries — for example, a CHUNK_MINMAX row describing a chunk that lies entirely in [NROWS, extent) — MAY be present as residue from preallocation or from a previous, larger table state, and MUST be ignored.

For list columns the cutoff applies through the top-level OFFSETS: rows [0, NROWS) define the valid slices, positions of OFFSETS beyond NROWS (and of MASK beyond NROWS) are reserved storage, and elements of any VALUES member beyond OFFSETS[NROWS] (applied recursively through nested levels) have no semantic meaning and MUST be ignored.

12.2Index validity tokens¶

Search indexes are derivative data, and this section places the burden of keeping them consistent on producers. Validity tokens give consumers a cheap, constant-time way to detect when that burden was not met — a crashed producer, an interrupted rebuild, or a tool that modified column data without maintaining indexes — without validating an index against the column it describes.

The `GENERATION` attribute¶

A table group that contains one or more search-index datasets MUST carry a scalar attribute named GENERATION of datatype uint64. A table group with no search-index datasets MAY omit it.

GENERATION identifies the current state of the table’s column data. A producer MUST increment GENERATION by one as part of any operation that:

modifies the value of any element of any column at a row position in [0, NROWS) — including the member datasets of a list column — or
commits a change to NROWS (append, §12.3; truncation, §12.5).

GENERATION is compared by equality only. Producers MUST NOT assign meaning to its magnitude beyond distinguishing successive states, and consumers MUST NOT order table states by comparing GENERATION values. The initial value is unspecified; 0 is RECOMMENDED.

Schema operations — adding, removing, or renaming columns — do not require an increment. Index linkage is per column and by object reference (§5): removing a column removes the SEARCH_INDEX_LIST attribute through which its indexes were reachable, adding a column affects no existing index, and renaming changes nothing an object reference resolves through. A producer MAY increment GENERATION on schema operations anyway; a spurious increment is safe — it can only disable indexes, never validate stale ones.

Per-index source tokens¶

Every search-index dataset MUST carry two scalar attributes of datatype uint64:

SOURCE_GENERATION: The value that GENERATION holds — or will hold, once the table state this index describes is committed — for the state the index content was built against.
SOURCE_NROWS: The value that NROWS holds, or will hold, for that same state.

Building a new search index over an unchanged table is not a mutation: the producer writes SOURCE_GENERATION and SOURCE_NROWS equal to the table’s current GENERATION and NROWS (writing GENERATION first if the table did not previously carry it) and does not increment GENERATION.

Because GENERATION is table-wide, a mutation of one column also invalidates the indexes of columns that were not modified. Those indexes remain factually correct; a producer restores them by rewriting their SOURCE_GENERATION with the new value — an attribute-only write, no rebuild required.

Consumer validity check¶

Before using a search-index dataset, a consumer MUST evaluate:

SOURCE_GENERATION == GENERATION  AND  SOURCE_NROWS == NROWS

If either comparison fails, or if any of the four attributes is absent or of the wrong datatype, the consumer MUST behave as if the search-index dataset were not present. A failed check is not an error and MUST NOT cause the table to be rejected; it only disables index-accelerated access. Consumers MUST NOT partially trust a stale index — for example, by consulting a SORTED_ROWS permutation over the first SOURCE_NROWS rows of a longer table — because the token mismatch may equally stem from in-place modifications within those rows.

Write ordering¶

One invariant makes every crash state detectable: at every instant, a search-index dataset whose content does not correctly describe the committed table state MUST carry tokens that fail the validity check. The invariant dictates opposite update orders for the two kinds of mutation:

Mutations gated by the NROWS commit (append, truncation): the rebuilt index describes a future state, so the producer MUST write the future-valued tokens before modifying the index content. The new SOURCE_GENERATION does not yet exist on the table group, so the index fails the check throughout its own rebuild; a crash mid-rebuild leaves it detectably stale rather than plausibly valid.
Immediately visible mutations (in-place updates, §12.6): the producer MUST commit the GENERATION increment (and flush) before writing any column data, disabling every index up front, and MUST rewrite each index’s tokens only after that index’s content is again correct. Writing current-valued tokens before the content would let a mid-rebuild index pass the check.

According to the append protocol (§12.3), a crash before the GENERATION write leaves the old table state fully usable with its old, still-valid indexes — appended data is invisible. A crash between the GENERATION and NROWS writes leaves the table readable at the old NROWS with no valid indexes: rebuilt indexes fail the SOURCE_NROWS comparison, untouched ones the SOURCE_GENERATION comparison. SOURCE_NROWS exists precisely for that window — with SOURCE_GENERATION alone, a rebuilt index would appear valid in it. No write ordering between the GENERATION and NROWS attributes themselves is required: if NROWS happens to reach storage first and the producer crashes, updated indexes fail on SOURCE_GENERATION instead. Both orders are detectably stale.

These guarantees are conditional on the integrity of the HDF5 file itself: HDF5 does not journal its own metadata, and the crash-consistency statements of this section describe the HEP001-level state of a file that survives the crash structurally intact.

12.3Appending rows¶

A producer that appends K new rows to a table MUST perform the operation in the following order, treating step 6 as the single commit point that publishes the new rows to readers:

Read the current NROWS and GENERATION (call them N_old and g_old). A table with no search-index datasets carries no GENERATION and skips the token-related parts of steps 4–5.
Extend every column dataset so that its first-dimension extent is ≥ N_old + K. A column that already has spare capacity from a prior preallocation needs no extension; the requirement is the post-condition extent ≥ N_old + K on every column. For every list column, extend the member datasets to their own post-conditions: top-level OFFSETS extent ≥ N_old + K + 1, MASK (when present) extent ≥ N_old + K, and each VALUES member (recursively) large enough for the elements being appended.
Write the new row values into rows [N_old, N_old + K) of each column. Writes MAY proceed in any order across columns. Within a list column, write leaf-first: element values at the deepest level first, then each enclosing level’s OFFSETS (and MASK), ending with the top-level OFFSETS entries [N_old + 1, N_old + K] — so that at every moment the already-committed rows [0, N_old) remain fully described.
Update the search indexes the producer chooses to maintain. For each such index: first write its SOURCE_GENERATION = g_old + 1 and SOURCE_NROWS = N_old + K — the tokens-before-content rule of §12.2 — then rebuild or update its content so that, after step 6 commits, it correctly describes rows [0, N_old + K). For index families that support efficient incremental updates (CHUNK_MINMAX, CHUNK_BLOOM), a producer MAY simply append new entries; for families that do not (SORTED_ROWS, BITMAP), the producer typically rebuilds the index from scratch. Indexes the producer does not maintain MAY be left untouched — the validity check disables them — or deleted together with the corresponding references in each column’s SEARCH_INDEX_LIST.
Write GENERATION = g_old + 1 (when the table carries GENERATION).
Commit by writing NROWS = N_old + K as the final step. The attribute update SHOULD be followed by an H5Fflush (or equivalent) before the producer reports the append as complete.

The ordering is critical for crash recovery. Until step 6 commits, every consumer that opens the file still sees NROWS = N_old and therefore the table exactly as it was before the append. A producer that crashes anywhere in steps 1–4 leaves a file whose observable state is identical to the pre-append state: the unused tail in [N_old, extent) is reserved storage, any index residue beyond N_old is ignored, and indexes rewritten in step 4 fail the validity check. A crash after step 5 but before step 6 additionally disables all of the table’s search indexes until a producer refreshes or rebuilds them (§12.2). The table data remains fully readable. No cleanup is required for readers to use the file correctly. A subsequent producer that wants to retry the append SHOULD either overwrite the unused tail or extend further.

As with every crash-consistency statement in this document, the above describes the HEP001-level state of a file that survives the crash structurally intact (§12.2). HDF5 does not journal its own metadata: a crash during any metadata write — a dataset extension, an attribute update, a B-tree modification — MAY corrupt the HDF5 file itself, beyond what this specification’s ordering rules can protect. Producers that require durability against file-level corruption MUST arrange it outside HDF5 (for example, journaled or copy-on-write storage, filesystem snapshots, or write-ahead copies of the file).

HDF5 itself does not guarantee atomic ordering between the data writes of step 3, the index writes of step 4, and the attribute updates of steps 5–6 unless the producer issues explicit H5Fflush calls between them. A producer that requires strong durability across a crash MUST issue an H5Fflush after step 4 and again after step 6, so that the on-disk state cannot show NROWS = N_old + K together with unwritten column data or stale indexes.

Note

The commit point of this workflow is a modification of the table group’s NROWS attribute. The original HDF5 SWMR (Single-Writer/Multiple-Reader) feature cannot be used to publish an append this way: an SWMR writer may only append raw data to existing datasets along an unlimited dimension and MUST NOT create or modify attributes — or any other metadata — while SWMR writing is active. Producers that need live concurrent readers therefore cannot rely on classic SWMR for the NROWS commit. The prototype VFD SWMR feature does permit attribute creation and modification while writing, but as of this revision it has not shipped in any stable HDF5 release — it exists on a development feature branch only. Until it ships, live concurrent reading of a table under active append requires coordination outside HDF5.

12.4Preallocation¶

A producer MAY extend column datasets past the current NROWS to amortize the cost of H5Dset_extent across many small appends — for example, extending by one chunk’s worth of rows at a time and filling that chunk over several append batches. The extended tail is reserved storage; its contents have no semantic meaning under HEP001 until a subsequent commit (step 6 above) increases NROWS to cover them.

A producer that preallocates SHOULD ensure that all columns in the same table group remain at equal first-dimension extents after each operation (see §13). The simplest and recommended discipline is to preallocate every column by the same number of rows at the same time.

12.5Truncation¶

A producer MAY shrink the logical table by writing a smaller NROWS value. The truncation is logical: the column datasets MAY retain their old extents, with rows [new_NROWS, old_NROWS) becoming reserved storage. A producer that wants to reclaim physical space MUST rewrite each column dataset to its new extent.

The same logical truncation applies to list columns with no additional writes: the smaller NROWS shrinks the valid top-level OFFSETS range to [0, new_NROWS], and OFFSETS[new_NROWS] becomes the bound on valid elements at every nested level (§9.3). Positions and elements beyond those bounds become reserved storage. Reclaiming their physical space likewise requires rewriting the affected member datasets to their new logical sizes.

The same index rules that govern appends apply on truncation, with new_NROWS in place of N_old + K: the producer either maintains an index (tokens first, then content; steps 4–6 of §12.3), deletes it (removing the corresponding SEARCH_INDEX_LIST entry on the column), or leaves it untouched to be disabled by the validity check (§12.2).

12.6In-place updates¶

A producer MAY rewrite individual cells of the table — change the value at one or more row positions < NROWS — without altering NROWS. Unlike appended rows, in-place writes are visible to consumers the moment they reach the file, so the mutation MUST follow the invalidate-first ordering of §12.2:

Write GENERATION = g_old + 1 and flush (H5Fflush). From this point, every search index in the table fails the validity check. (A table with no search indexes carries no GENERATION and skips steps 1 and 3.)
Write the new cell values.
Restore search indexes. For each index over a modified column: rebuild or update its content first, then write its SOURCE_GENERATION = g_old + 1 (SOURCE_NROWS is unchanged) content before tokens, because the new generation is already committed. For each index over an unmodified column, rewriting SOURCE_GENERATION alone suffices. Indexes the producer does not restore MAY be left disabled or deleted. Flush.

A crash before step 2 leaves the data unchanged and every index disabled but factually correct — a subsequent producer MAY restore them by rewriting tokens alone. A crash during step 2 leaves possibly partial data with every index disabled. In-place updates of the data itself do not benefit from the single-attribute commit point that NROWS provides; producers that require atomic semantics for in-place edits MUST arrange them externally (for example, by writing to a fresh column dataset and swapping it in under a future revision of this HEP, or by using application-level coordination outside HDF5).

13Consistency requirements¶

A conformant table group satisfies all of the following at all times:

The table group MUST carry a scalar NROWS attribute of datatype uint64 (see §7.3).
Every column dataset (including row index columns) in the same table group MUST have the same first-dimension extent, and that extent MUST be ≥ NROWS.
Every search-index dataset in the SEARCH_INDEXES group MUST carry a KIND attribute. The only other datasets permitted in the SEARCH_INDEXES group are the accompanying datasets those search indexes require, and an accompanying dataset MUST NOT carry a KIND attribute.
Every reference in a column’s SEARCH_INDEX_LIST MUST resolve to a search-index dataset under the table group’s SEARCH_INDEXES subgroup.
Every categorical column’s CATEGORIES reference MUST resolve to a categories dataset in the table group’s CATEGORIES subgroup (§8.7). The CATEGORIES subgroup, when present, MUST contain only categories datasets, and every categories dataset MUST be referenced by at least one categorical column’s CATEGORIES attribute.
column-order, when present, MUST list every column of the table (column datasets and list columns) exactly once and MUST NOT list any object that is not a column (in particular, not a categories dataset, a search-index dataset, or a member of a list column group).
Every reference in the table group’s INDEX_COLUMNS attribute (when present) MUST resolve to a column dataset that is a direct child of the table group, MUST NOT be a null reference, and MUST NOT resolve to a list column group; when _index is also present, it MUST equal the dataset name of the column referenced by INDEX_COLUMNS[0].
Every categorical column’s fill value (see §8.5) MUST NOT collide with a valid integer code in the linked categories dataset’s index range, so that the canonical missing-value test (§8.5) unambiguously denotes “missing category” rather than “valid value at category index fill.”
Every search-index dataset whose validity check (§12.2) passes MUST correctly describe its source column for row positions in [0, NROWS). Tail entries that describe positions ≥ NROWS — for example, residue from preallocation or from a prior truncation — MAY be present and MUST be ignored by consumers. A search-index dataset whose validity check fails is exempt from this requirement; consumers treat it as absent.
Every list column group MUST satisfy the structural rules of List columns at every level: CLASS and KIND attributes present; OFFSETS[0] = 0 and monotonically non-decreasing over [0, L] with extent ≥ L + 1 for that level’s entry count L; MASK, when present, of extent ≥ L, with OFFSETS[i+1] = OFFSETS[i] for every entry whose MASK[i] is FALSE; and a VALUES member that is a rank-1 dataset, a conformant nested list column group, or a conformant STRING_VALUES group.
No variable-length datatype occurs anywhere below a list column group (§9.5).
When a table group contains one or more search-index datasets, the table group MUST carry a scalar uint64 GENERATION attribute, and every search-index dataset MUST carry scalar uint64 SOURCE_GENERATION and SOURCE_NROWS attributes (§12.2).
Every boolean column (§8.8) carries the HEP001 boolean datatype, holds only the values 0 and 1 at row positions in [0, NROWS), and declares no user-defined fill value.

A producer that mutates a table (appends rows, truncates, rewrites a column, etc.) MUST follow §12 — for each affected search index, either updating it consistently, deleting it, or leaving it to be disabled by the validity check.

14Reserved names¶

HEP001 follows the long-standing HDF Group High-Level API practice — established by the HDF5 Table, Image, and Dimension Scales specifications — of writing reserved attribute and group names in fixed-length ASCII, UPPERCASE. The intent is that a reader scanning an HDF5 file can tell at a glance which names belong to the specification and which were chosen by the producer of the data.

14.1Naming rules¶

Every attribute or group name introduced as part of the HEP001 specification MUST be written in fixed-length uppercase ASCII, with underscores as the only word separator (for example, CLASS, INDEX_COLUMNS, SEARCH_INDEXES).
Producers MUST NOT use any reserved name listed in Section 14.2 for a column dataset, a search-index dataset, a user-supplied attribute, or any other purpose other than the one this HEP assigns to it.
Names that HEP001 deliberately borrows from other ecosystems, currently only from Anndata’s DataFrame layout (§16), are exempt from rule 1 and MUST be written exactly as those ecosystems write them. They are listed in Section 14.3.
Several attributes that align with broader scientific HDF5 community practice are exempt from rule 1 and MUST be written in lowercase, so that generic metadata harvesters and existing tools can discover them on a HEP001 table without case-folding.
The descriptive annotation attributes units, units_vocabulary, and description are lowercase and carry no contractual meaning: their presence, absence, or value does not change how a HEP001 consumer interprets the table or any of its objects. They are defined alongside the objects that may carry them (The table group, Column datasets) and do not appear in the reserved-name catalog. Any future descriptive annotation attribute introduced by this HEP or a successor MUST follow the same lowercase convention.
The value-domain attributes valid_min and valid_max, when present on a column dataset, carry contractual meaning: the column’s fill value MUST lie strictly outside [valid_min, valid_max] (see §8.5). They appear in the reserved-name catalog (Section 14.2) despite being lowercase.
Per-search-index attributes that are private to a specific search-index family — including configuration parameters, declarations of the algorithm used, and computed output metrics — are not part of the reserved name contract and are written in lowercase snake_case. They are documented with the index family that defines them (Search indexes).
KIND values (the string contents of the KIND attribute) are themselves reserved tokens and follow the same uppercase rule as reserved names.

14.2Reserved name catalog¶

The complete set of HEP001 reserved names is listed below.

Group names¶

CATEGORIES: The reserved subgroup of a table group that holds every categories dataset for the table. See Section 8.7. The token CATEGORIES names both this group and the column attribute of the same name below; the two are unambiguous because one is an HDF5 link name and the other an attribute name, but producers should be aware of the overload.
SEARCH_INDEXES: The reserved subgroup of a table group that holds every search-index dataset for the table. See Search indexes.

List column member names¶

The following dataset names are reserved inside list column groups and STRING_VALUES groups (List columns). A list column group itself is named by the producer (its name is the column name); only its members carry reserved names.

OFFSETS: The offsets dataset of a list column or STRING_VALUES group.
VALUES: The flattened-elements member of a list column group: a rank-1 leaf dataset, a nested list column group, or a STRING_VALUES group. Shares its token with the VALUES attribute of BITMAP search indexes below; the two are unambiguous because one is an HDF5 link name and the other an attribute name.
MASK: The optional null-entry mask dataset of a list column or STRING_VALUES group.
CHARS: The UTF-8 byte-buffer dataset of a STRING_VALUES group.

Table group attribute names¶

CLASS: Identifies the role of a HEP001 group. On a table group its value is COLUMN_TABLE (Section 7.1); on a list column group, LIST_COLUMN; on the string-elements group of a list column, STRING_VALUES (List columns). The value strings are reserved tokens.
VERSION: HEP001 revision the table conforms to.
NROWS: Scalar uint64. Number of logical rows currently in the table. See §7.3.
TITLE: Human-readable title of the table (optional).
INDEX_COLUMNS: A 1-D array attribute of HDF5 object references, whose elements point to the column datasets that serve as row labels for the table, in hierarchical order from outermost to innermost level. See Row index columns.
GENERATION: Scalar uint64. State identifier of the table’s column data, used by the index validity check. See §12.2.

Column dataset attribute names¶

SEARCH_INDEX_LIST: Object references to the search-index datasets that accelerate queries on this column.
CATEGORIES: Object reference to the categories dataset, in the table group’s CATEGORIES subgroup, that backs a categorical column. Shares its token with the CATEGORIES group above.
valid_min, valid_max (lowercase, by exception): Inclusive lower and upper bounds of the column’s logical value range. Each is a scalar attribute whose datatype matches the column’s element datatype. See §8.5.
MASK (reserved for a future revision): Reserved name for a per-row validity-mask mechanism on column datasets; producers conforming to this revision MUST NOT write it. See §??.

Search-index and categories dataset attribute names¶

KIND: ASCII string that identifies the family of a search-index dataset, or the storage method of a list column group (§9.1). The two value sets are disjoint and are interpreted according to the object that carries the attribute.
VALUES: Object reference, on a BITMAP search-index dataset, to its accompanying values dataset. Shares its token with the VALUES member name of list column groups above.
SOURCE_GENERATION, SOURCE_NROWS: Scalar uint64 validity tokens carried by every search-index dataset, recording the table state the index content was built against. See §12.2.

`KIND` attribute values¶

On search-index datasets:

CHUNK_MINMAX
SORTED_ROWS
BITMAP
CHUNK_BLOOM

See Search indexes for their meaning. Consumers MUST treat unknown values as “ignore this search index”.

On list column groups:

OFFSETS

See List columns for its meaning. A consumer that does not implement a list column’s KIND MUST NOT silently drop the column (§9.1).

14.3Names shared with Anndata¶

The following attribute names and string values are borrowed from Anndata’s DataFrame layout (§16) and are written in lowercase, exactly as Anndata writes them, so that a producer targeting an Anndata converter does not have to case-fold. They are reserved for their Anndata-defined meaning and MUST NOT be repurposed:

attribute names — column-order, _index, encoding-type, encoding-version, ordered;
string values — "dataframe" and "categorical" when written into an encoding-type attribute.

Of these, HEP001 itself uses column-order, _index, and ordered (§7, §6); encoding-type, encoding-version, and the string values are optional pass-through names that HEP001 does not interpret. A producer MAY omit any of these names, but if it writes one at all it MUST use this exact form (lowercase, with the hyphens and underscore as shown).

15Worked examples¶

15.1A minimal table¶

A table of four columns — row_id (the row index), ts, energy, label — and no search indexes.

/my_table                          (Group)
  CLASS             = "COLUMN_TABLE"   (ASCII, fixed length)
  VERSION           = "1.0"            (ASCII, fixed length)
  NROWS             = N                (uint64, scalar)
  TITLE             = "Sample run"     (UTF-8)
  column-order      = ["row_id", "ts", "energy", "label"]  (UTF-8, 1-D)
  INDEX_COLUMNS     = [ref(row_id)]    (1-D object references)
  _index            = "row_id"         (UTF-8; primary row-label name)

/my_table/row_id                   (Dataset, uint64, shape (N,))
  description       = "Globally unique event identifier."

/my_table/ts                       (Dataset, int64, shape (N,))
  units             = "s"
  units_vocabulary  = "UDUNITS-2"
  description       = "Event timestamp."

/my_table/energy                   (Dataset, float32, shape (N,))
  units             = "MeV"

/my_table/label                    (Dataset, int8, shape (N,))
  description       = "Class label."
  CATEGORIES        = ref(CATEGORIES/label__CATEGORIES)

/my_table/CATEGORIES               (Group)

/my_table/CATEGORIES/label__CATEGORIES   (Dataset, vlen UTF-8, shape (3,))
  ordered           = false

15.2A table with list columns¶

Extending §15.1 with two list columns: readings (list<float32>, with null lists possible) and tags (list<utf8>, unbounded string elements, no null lists):

/my_table
  column-order      = ["row_id", "ts", "energy", "label",
                       "readings", "tags"]
  …

/my_table/readings                 (Group)
  CLASS             = "LIST_COLUMN"    (ASCII, fixed length)
  KIND              = "OFFSETS"        (ASCII, fixed length)
  description       = "Per-event auxiliary sensor readings."

/my_table/readings/OFFSETS         (Dataset, uint64, shape (N+1,))
/my_table/readings/MASK            (Dataset, bool enum, shape (N,))
/my_table/readings/VALUES          (Dataset, float32, shape (M,))
  units             = "V"

/my_table/tags                     (Group)
  CLASS             = "LIST_COLUMN"
  KIND              = "OFFSETS"

/my_table/tags/OFFSETS             (Dataset, uint64, shape (N+1,))
/my_table/tags/VALUES              (Group)
  CLASS             = "STRING_VALUES"

/my_table/tags/VALUES/OFFSETS      (Dataset, uint64, shape (M2+1,))
/my_table/tags/VALUES/CHARS        (Dataset, uint8, shape (B,))

Row i of readings is VALUES[OFFSETS[i] : OFFSETS[i+1]], unless MASK[i] is FALSE, in which case the list is null. Row i of tags resolves through two offsets levels: entry j of the row’s slice is the UTF-8 decoding of CHARS[VALUES/OFFSETS[j] : VALUES/OFFSETS[j+1]].

15.3Adding a chunk min/max search index¶

Extending §15.1 with a CHUNK_MINMAX index on ts:

/my_table
  GENERATION        = g                (uint64; index validity token)
  …

/my_table/ts
  SEARCH_INDEX_LIST = [ref(SEARCH_INDEXES/ts__chunk_minmax)]
  …

/my_table/SEARCH_INDEXES                       (Group)
/my_table/SEARCH_INDEXES/ts__chunk_minmax      (Dataset,
    compound {min: int64, max: int64, nan_count: uint64,
              fill_count: uint64, n: uint64}, shape (n_chunks,))
  KIND              = "CHUNK_MINMAX"
  SOURCE_GENERATION = g                (uint64; matches GENERATION)
  SOURCE_NROWS      = N                (uint64; matches NROWS)

15.4A complete layout¶

The diagram below assembles the pieces of the preceding examples into one table group: four column datasets (one designated as the row index), a categorical column with its categories dataset, a list column with its member datasets, and four search indexes. The GENERATION attribute is present because the table carries search indexes; the per-index SOURCE_GENERATION and SOURCE_NROWS validity tokens (§12.2) are omitted from the diagram for brevity.

16Relationship to Anndata¶

Anndata is the most direct inspiration for HEP001: HEP001 adopts the same group-of-one-dataset-per-column shape and deliberately reuses several of Anndata’s attribute names (column-order, _index, ordered) so that converters between the two are straightforward. HEP001 is not, however, a drop-in Anndata DataFrame format, and this document does not specify Anndata read/write conformance. The two layouts diverge on points that matter for typical tabular data — Anndata encodes categoricals and nullable columns as subgroups (with codes/categories or values/mask children) and tags every column array with an encoding-type, whereas HEP001 keeps each column as a single rank-1 dataset and records missing values through fill values. Because an HDF5 link resolves to one object, a column that Anndata stores as a subgroup cannot simultaneously be a HEP001 column dataset. A single group can therefore satisfy both specifications only for the restricted case of dense numeric and variable-length string columns with no categorical or nullable columns; anything richer requires an explicit import/export step. HEP001 reserves the Anndata-derived attribute names (§14.3) so producers may write them when targeting such a converter, but assigns them no HEP001 meaning.

17Security considerations¶

Search indexes are unsigned, untrusted derivative data. A consumer that trusts a table’s column data MUST NOT, by default, trust the correctness of a search index found in the same file: a tampered CHUNK_MINMAX can cause the consumer to skip chunks that do in fact satisfy a predicate. The validity tokens of §12.2 detect accidental staleness only and add nothing against tampering — an adversarial writer can trivially forge matching tokens. Consumers SHOULD offer a mode that verifies a search index against the column it covers, or that ignores search indexes entirely. Producers SHOULD document the provenance of search indexes in the table group’s description or in each search-index dataset’s description attribute when that matters to their users.

18References¶

HDF5 file format specification — The HDF Group. https://docs.hdfgroup.org/hdf5/develop/_f_m_t3.html
HDF5 Table specification — HDF5 High-Level Library, The HDF Group. https://support.hdfgroup.org/documentation/hdf5/latest/_t_b_l_s_p_e_c.html
PyTables File Format — PyTables Users’ Guide. https://www.pytables.org/usersguide/file_format.html
Anndata on-disk format (DataFrames) — Anndata documentation. https://anndata.readthedocs.io/en/stable/fileformat-prose.html#dataframes
Apache Parquet format specification. https://parquet.apache.org/docs/file-format/
Apache Arrow columnar format. https://arrow.apache.org/docs/format/Columnar.html
RFC 2119 — Key words for use in RFCs to Indicate Requirement Levels. S. Bradner, 1997. https://datatracker.ietf.org/doc/html/rfc2119
RFC 8174 — Ambiguity of Uppercase vs Lowercase in RFC 2119 Key Words. B. Leiba, 2017. https://datatracker.ietf.org/doc/html/rfc8174
IEEE Std 754-2019 — IEEE Standard for Floating-Point Arithmetic. IEEE, 2019. DOI: 10.1109/IEEESTD.2019.8766229
Semantic Versioning 2.0.0 — T. Preston-Werner. https://semver.org/spec/v2.0.0.html
Unicode Standard Annex #15 — Unicode Normalization Forms. The Unicode Consortium. https://www.unicode.org/reports/tr15/
MurmurHash3 — A. Appleby, SMHasher project. https://github.com/aappleby/smhasher/wiki/MurmurHash3
A. Kirsch and M. Mitzenmacher, “Less Hashing, Same Performance: Building a Better Bloom Filter,” in Algorithms — ESA 2006 (LNCS 4168), pp. 456–467, 2006. DOI: 10.1007/11841036_42

H5Col: Column-Oriented Tabular Data in HDF5

1Introduction¶

1.1A short overview of tabular data in HDF5¶

1.2Why columnar, and why now¶

1.3Scope and non-goals¶

2Conformance¶

2.1Datatype byte order¶

3Terminology¶

4Data model overview¶

5Object references¶

6The boolean datatype¶

7The table group¶

7.1Identification — the CLASS attribute¶

7.2The VERSION attribute¶

7.3The NROWS attribute¶

7.4Optional table group attributes¶

7.5Placement of the table group¶

7.6Self-contained contents¶

8Column datasets¶

8.1Required properties¶

8.2Column discovery¶

8.3Datatypes¶

8.4Chunking and filters¶

8.5Missing values (fill values)¶

Full-domain columns¶

Reserved: the MASK column attribute¶

8.6Column attributes¶

8.7Categorical columns¶

The CATEGORIES group¶

Categorical column requirements¶

8.8Boolean columns¶

Values¶

Missing values¶

Interaction with search indexes¶

9List columns¶

9.1Identification¶

9.2Members of a list column group¶

9.3Levels, entries, and nesting¶

9.4String elements — the STRING_VALUES group¶

9.5No variable-length datatypes¶

9.6List column attributes¶

9.7Reading a list column¶

10Row index columns¶

10.1Hierarchy¶

10.2Typical uses¶

11Search indexes¶

11.1The SEARCH_INDEXES group¶

11.2Linking columns to search indexes¶

11.3Common per-index attributes¶

11.4Chunk min/max search index (KIND = CHUNK_MINMAX)¶

11.5Sorted-row permutation index (KIND = SORTED_ROWS)¶

11.6Bitmap index (KIND = BITMAP)¶

11.7Per-chunk Bloom filter index (KIND = CHUNK_BLOOM)¶

12Writing and appending data¶

12.1How consumers interpret NROWS¶

12.2Index validity tokens¶

The GENERATION attribute¶

Per-index source tokens¶

Consumer validity check¶

Write ordering¶

12.3Appending rows¶

12.4Preallocation¶

12.5Truncation¶

12.6In-place updates¶

13Consistency requirements¶

14Reserved names¶

14.1Naming rules¶

14.2Reserved name catalog¶

Group names¶

List column member names¶

Table group attribute names¶

Column dataset attribute names¶

Search-index and categories dataset attribute names¶

KIND attribute values¶

14.3Names shared with Anndata¶

15Worked examples¶

15.1A minimal table¶

15.2A table with list columns¶

15.3Adding a chunk min/max search index¶

15.4A complete layout¶

7.1Identification — the `CLASS` attribute¶

7.2The `VERSION` attribute¶

7.3The `NROWS` attribute¶

Reserved: the `MASK` column attribute¶

The `CATEGORIES` group¶

9.4String elements — the `STRING_VALUES` group¶

11.1The `SEARCH_INDEXES` group¶

11.4Chunk min/max search index (`KIND = CHUNK_MINMAX`)¶

11.5Sorted-row permutation index (`KIND = SORTED_ROWS`)¶

11.6Bitmap index (`KIND = BITMAP`)¶

11.7Per-chunk Bloom filter index (`KIND = CHUNK_BLOOM`)¶

12.1How consumers interpret `NROWS`¶

The `GENERATION` attribute¶

`KIND` attribute values¶
